How do you validate a APHA/Pt-Co/Hazen 500 liquid color standard?

As described in Section 6 of ASTM D1209, there are 2 criteria to validate a APHA/Pt-Co 500 standard:

• The APHA/Pt-Co 500 Color Standard must have a defined chemical composition and be prepared in accordance with section 6 of ASTM D1209.
• After preparation, the APHA/Pt-Co 500 standard must meet a absorbance criteria at 4 points in the blue region of the visible spectrum per Table 1 of ASTM D1209.

1. Platinum-Cobalt Reference Standards

6.1 Platinum-Cobalt Stock Solution— Dissolve 1.245 g of potassium chloroplatinate (K2PtCl6) and 1.00 g of cobalt chloride (CoCl2·6H2O) in water. Carefully add 100 mL of hydrochloric acid (HCl, sp gr 1.19) and dilute to 1 L with water. The absorbance of the 500 platinum-cobalt stock solution in a cell having a 10 mm light path, with reagent water in a matched cell as the reference solution, must fall within the limits given in Table 1.

ASTM D1209 TABLE 1 Absorbance Tolerance Limits For No. 500 Platinum-Cobalt Stock Solution

Wavelength, nmAbsorbance, A4300.110 to 0.1204550.130 to 0.1454800.105 to 0.1205100.055 to 0.065

How to Validate a APHA/Pt-Co/Hazen 500 Color Standard

• In the Spectral Data View of EasyMatch QC, place your mouse over the view and Right Click/Configure to report Absorbance spectral data instead of Transmission. In the Spectral Data View of EasyMatch QC, place your mouse over the view and Right Click/Configure to report Absorbance spectral data instead of Transmission. If you do not have a Spectral Data View displayed, put your mouse over the Color Data Table/Right Click/Split Horizontally and Add Spectral Data View.
• Fill a 10 mm path length cell with distilled water and place on transmission bench on a HunterLab diffuse d/8 sphere instrument.
• Standardize in TTRAN LAV (Large Area of View) UV Filter in the Nominal position using the Light Blocker and 10 mm cell + DI water to set bottom and top-of-scale.
• As a PQ Performance Qualification step, read back the cell + DI water as an OQ (Operation Qualification) step. The transmission at 430, 455, 480 and 510-nm should be 100% with the corresponding absorbance being 0%.
• Read the APHA/Pt-Co 500 Liquid Color Standard to see if it reads within the absorbance tolerances at 430, 455, 480 and 510 nm in Table 1 of ASTM D1209. If your instrument only reports at 10 nm intervals. Average the absorbance at 450 and 460 nm.

If the APHA/Pt-Co/Hazen 500 Color Standard meets both the chemical and absorbance criteria of ASTM D1209, it is a 500 Standard.
